290120 SPS RECTIFIER BAY, 208VAC, THREE RECTIFIERS PER FEED

(No reviews yet) Write a Review
SKU:
290120
$45,203.29
Frequently bought together:

Description

290120 SPS RECTIFIER BAY, 208VAC, THREE RECTIFIERS PER FEED, INPUT BREAKERS, 2760A OUTPUT POWERPACK RECTIFIER BAY, QTY 12 RECTIFIER POSITIONS, 3 PHASE 208VAC AC FEED,EACH RECTIFIER IS CONFIGURED WITH ONE 3-POLE 60A AC BREAKER RATED 65KA FOR INTERRUPTING CAPACITY. THREE RECTIFIERS PER AC FEED, TOTAL 4 AC FEEDS, EVERY AC FEED INCLUDES TWO 1/4""-20 STUDS ON 5/8"" CENTER,RAISED 10KA BUS STRUCTURE INCLUDES: 10KA HOT AND RETURN BUSES, QTY 10 (20 BACK TO BACK) CONNECTION LANDINGS ON BOTH BUSES, EACH LANDING INCLUDES TWO 3/8"" HOLES ON 1"" CENTERSMARTPACK2 CONTROLLER, INCLUDING SMARTPACK2 BASIC (242100.501) WITH SD CARD, SMARTPACK2 MASTER (242100.500), AND QTY 2 I/O MONITOR MODULES (242100.502). QTY 12 FORM-C RELAY OUTPUTS, QTY 12 CONFIGURABLE INPUTS, ETHERNET PORT FOR REMOTE OR LOCAL MONITORING AND CONTROL."
