IP Series PermaSleeve Polyolefin Wire Marking Sleeves SINGLE-SIDED, 2500 sleeves per roll; 20-10 wire gage

(No reviews yet) Write a Review
SKU:
PS-187-2-WT
Availability:
.
  • IP Series PermaSleeve Polyolefin Wire Marking Sleeves SINGLE-SIDED, 2500 sleeves per roll; 20-10 wire gage
  • IP Series PermaSleeve Polyolefin Wire Marking Sleeves SINGLE-SIDED, 2500 sleeves per roll; 20-10 wire gage
  • IP Series PermaSleeve Polyolefin Wire Marking Sleeves SINGLE-SIDED, 2500 sleeves per roll; 20-10 wire gage
  • IP Series PermaSleeve Polyolefin Wire Marking Sleeves SINGLE-SIDED, 2500 sleeves per roll; 20-10 wire gage
  • IP Series PermaSleeve Polyolefin Wire Marking Sleeves SINGLE-SIDED, 2500 sleeves per roll; 20-10 wire gage
$2,029.00
Frequently bought together:

Description

IP Series PermaSleeve Polyolefin Wire Marking Sleeves SINGLE-SIDED, 2500 sleeves per roll; 20-10 wire gauge

Part Number: PS-187-2-WT

Material: Polyolefin

For Use with Printer: BRADY IP® Series Label Printer, BradyPrinter i5100, BradyPrinter i7100, BRADYPRINTER PR Plus Series Label Printer

Material Number: B-342

Color: White

Quantity per Roll: 2500

OVERVIEW

PermaSleeve® PS Heat-Shrink Polyolefin (B-342) wire marking sleeves combine speed, ease of use, and permanence to create long-lasting, high quality identification.

  • 3:1 heat shrinkable sleeve fit snugly around wires for maximum insulation protection and permanent identification
  • Fade-resistant and smudge-proof for superior aesthetic appearance
  • Cold resistant and flame-retardant with an operating temperature of -67°F to 275°F (-55°C to 135°C)
  • Meets SAE-AMS-DTL-23053/5C (Class 1), SAE-AS-81531, MIL-STD-202; RoHS Compliant; and UL Recognized

SPECIFICATIONS

Material Number B-342
Catalog Page # 200
Diameter as Supplied 0.187 in
Dimensions 0.335 in H
UOM Roll of 2500 Each
Finish Matte
Maximum Service Temperature °F 275 °F
Maximum Wire Diameter 0.15 in
Maximum Wire Gauge 10 AWG
Minimum Service Temperature °F -67 °F
Minimum Wire Diameter 0.062 in
Minimum Wire Gauge 20 AWG
Printable Sides Single-Side Printable
Product Number 32602
UPC 662820326021
Quantity per Roll 2500
Quantity per Row 1
Recovered Diameter 0.062 in
Roll Width 2 in
Shrink Ratio 3:1
Sleeve Size 0.187 in Dia x 2 in W
Sleeve Size(m) 4.8 mm Dia x 50.8 mm W
Sleeve Width 2 in
Trade Name Brady IP™ PermaSleeve®
Applications Cable & Wire Marking
Color White
For Use with Printer BRADY IP® Series Label Printer, BradyPrinter i5100, BradyPrinter i7100, BRADYPRINTER PR Plus Series Label Printer
Label/Media Format Roll
Label Properties Heat Shrink Sleeves
Material Polyolefin
Material Properties Flame-retardant, Heat-Shrinkable
Print Technology Thermal Transfer
Resistance Properties Chemical-Resistant, Corrosion-Resistant, Humidity-Resistant, Smear-Resistant, UV-Resistant, Weather-Resistant
Suggested Ribbon Series R2000, R4300, R4502S, R5000, R6600, R6700
