Burndy
Burndy YAV6CL1BOX Copper Lug 6 AWG #8-#10 Stud
(No reviews yet)
Write a Review
- SKU:
- YAV6C-L1-BOX
- UPC:
- 782000000000
- Availability:
- If this is a rush order that needs expediting please contact us via LIVE CHAT before placing your order, to confirm we have the full qty needed to ship immediately.
- Minimum Purchase:
- 100 units
Frequently bought together:
Description
Burndy YAV6CL1BOX Copper Lug 6 AWG #8-#10 Stud
Hylug; 6 AWG; 8-10; 1.31 in L; .46 in W; Tin- Electro plated
Product Specifications
| Dimensional | |||||
| Tongue Angle | Straight | ||||
| Length (in) | 1.31 | ||||
| Tongue Type | Ring | ||||
| Stud Size (in) | #10,#8 | ||||
| Pad Width (in) | 0.46 | ||||
| Strip Length | 1/2" | ||||
| General | |||||
| Product Description | Hylug; 6 AWG; 8-10; 1.31 in L; .46 in W; Tin- Electro plated | ||||
| Other Features | |||||
| UPC | 781810539002 | ||||
| Other | |||||
| Installation Tooling | Non-Ratchet:MY28,MY29-11Ratchet:MR4C | ||||
| Bulk Package | YAV6CL1 | ||||
| Approvals / Certifications | |||||
| UL Listed | Y | ||||
| CSA Certified | Y | ||||
| ROHS Compatible | Compliant | ||||
| UL Recognized | N | ||||
| Mil-Spec Class Code | Class 1 | ||||
| CULUS | N | ||||
| Industry Standards | UL467,Military Specified (Mil-Spec) | ||||
| Conductor(s) | |||||
| Aircraft Cable Size (Range) | AN 6 | ||||
| Copper Solid Size (Range) | 10-8 | ||||
| Navy Cable Size (Range) | N/A | ||||
| Copper Stranded (Range) | 10-8 | ||||
| Physical | |||||
| Type of Plating | Tin | ||||
| Connector Type | Terminal | ||||
| Plated (Yes or No) | Y | ||||
This product comes with a manufacturer warranty
