Burndy YA4CL445 45 Degree Copper Lug 4 AWG 3/8" (Gray)

(No reviews yet) Write a Review
SKU:
YA4CL4-45
UPC:
782000000000
Availability:
If this is a rush order that needs expediting please contact us via LIVE CHAT before placing your order, to confirm we have the full qty needed to ship immediately.
Minimum Purchase:
10 units
$4.38
Frequently bought together:

Description

Burndy YA4CL445 45 Degree Copper Lug 4 AWG 3/8" (Gray)

Cu code conductor standard barrel, Single hole/W/ insp window, #4 AWG,3/8" stud, Tin plated, Grey, 8 index



Product Specifications

Dimensional
 Tongue Angle 45 Degree
 Length (in) 1.68
 Tongue Type Standard
 Barrel Style Chamfered,Skived
 Bolt Hole Size (in) 0.39
 Barrel Type Standard
 Thickness 0.08
 B Length (in) 0.81
 Pad Width (in) 0.58
 Strip Length 7/8
General
 Number of Holes 1
 Product Description Cu code conductor standard barrel, Single hole/W/ insp window, #4 AWG,3/8" stud, Tin plated, Grey, 8 index
Conductor(s)
 Flex (Class G) Size - Range N/A
 Flex (Class H) Size - Range N/A
 Flex (Class I) Size - Range N/A
 Copper Solid Size (Range) N/A
 DLO Size (Range) N/A
 Copper Stranded (Range) 4 AWG
Physical
 Type of Plating Tin - Electro Plated
 Bolt Hole Size 3/8
 Color Code Gray
 Plated (Yes or No) Y
 Index Number 8,346
 Product Material Copper
Approvals / Certifications
 UL Listed Y
 CSA Certified Y
 ROHS Compatible Compliant
 UL Recognized N
 CULUS View AllClose
